Databases

1. Database Normalization

1.1 Definition

• Normalization decomposes relations so that only related attributes remain together, eliminating anomalies and redundancy.

1.2 Anomalies

1. Insertion anomaly: need to insert unrelated data to add a new fact.
2. Update anomaly: modifying one duplicate tuple but not the others causes inconsistencies.
3. Deletion anomaly: removing a tuple unintentionally deletes valuable information.

Normalization uses functional dependencies to prevent these anomalies.

2. Functional Dependencies

2.1 Definition

• In relation R, if attribute set $X$ determines $Y$, we denote $X \rightarrow Y$—tuples with the same $X$ must share the same $Y$.

2.2 Guidelines

• Derive dependencies from attribute semantics and business rules, not from sample data alone.
• Primary and candidate keys typically determine all other attributes.

2.3 Full Functional Dependency

• $X \rightarrow Y$ but no proper subset of $X$ determines $Y$.
• Indicates $Y$ depends on the entire composite key.

2.4 Partial Functional Dependency

• When $Y$ depends on only part of a composite key.
• Break such relations into 2NF to remove partial dependencies.

3. Normal Forms

3.1 First Normal Form (1NF)

• All attribute values are atomic (no repeating groups or arrays).
• Remove multi-valued attributes. If non-key attributes do not fully depend on the key, move to 2NF.

3.2 Second Normal Form (2NF)

• In 1NF and every non-key attribute is fully functionally dependent on the primary key.
• Eliminates partial dependencies; composite-key relations may require decomposition.

3.3 Third Normal Form (3NF)

• In 2NF and no non-key attribute is transitively dependent on the primary key (no $A \rightarrow B$, $B \rightarrow C$ implying $A \rightarrow C$ among non-keys).

3.4 Boyce–Codd Normal Form (BCNF)

• Stronger than 3NF: every determinant in a functional dependency is a candidate key.
• Needed when multiple candidate keys exist and 3NF still allows anomalies.

Higher normal forms reduce redundancy but may increase join cost. Aim for a balance; 5NF is rarely necessary in practice.

3.5 Lossless Decomposition & Dependency Preservation

• Decompose relations without losing information and retain essential dependencies.
• Joining the decomposed tables must reconstruct the original data.

4. Views

4.1 Definition

• A view is a virtual table defined by a SELECT query over base tables. It stores no data, providing abstraction, reuse, and security.

4.2 Syntax

CREATE VIEW view_name [(column_list)]
AS
SELECT ...
[WITH CHECK OPTION];

• WITH CHECK OPTION enforces view predicates during DML operations.
• ORDER BY is not allowed inside view definitions; apply ordering when querying the view.

4.3 DML Restrictions

• View updates propagate to base tables only when:
  1. key and NOT NULL columns are present,
  2. no aggregates, DISTINCT, GROUP BY, or UNION,
  3. simple single-table views.
• Dropping a view leaves base tables intact, but drop dependent constraints first.

4.4 Benefits

• Simplify complex queries.
• Provide column-level access control.
• Maintain logical independence when base schema changes.

5. Indexing

5.1 What & Why

• An index is a data structure that enables fast record retrieval—most RDBMSs use B+ Trees (sometimes hashes).
• Conceptually stores key-value pairs (key → record address).

5.2 How It Works

1. Look up the search key in the index.
2. Follow the pointer to fetch the record, avoiding full table scans and reducing complexity to O(log n).

5.3 Design Considerations

• Best for selective predicates, frequent sorting/grouping, join keys, read-heavy workloads.
• Caveats: maintenance cost on INSERT/UPDATE/DELETE, functions/casts may prevent usage, low selectivity columns yield little benefit.

5.4 Clustered vs. Nonclustered

• Clustered index: table rows are stored in index order (e.g., InnoDB primary key).
• Nonclustered index: separate structure points to the actual data pages.

6. Triggers

6.1 Concept

• Stored routines that fire automatically in response to events (DML, DDL, login).
• Enforce integrity rules, record audit logs, maintain derived values.

6.2 Types

• BEFORE triggers: execute prior to the event—validate or adjust values.
• AFTER triggers: run post-event—log or cascade changes.
• INSTEAD OF triggers: mainly for views; intercept operations and apply custom logic.

6.3 Cautions

• Complex trigger chains can hurt performance or cause recursion.
• Failures roll back the entire transaction—add proper exception handling.

7. Stored Procedures

7.1 Definition

• Precompiled SQL code stored in the database; accepts parameters to automate recurring tasks.
• Executes on the server, reducing network trips and centralising business logic.

7.2 Example

CREATE PROCEDURE proc_name(IN p INT, OUT result VARCHAR(50))
BEGIN
  -- SQL statements
END;

• Invoke with CALL proc_name(value, @out);

7.3 Pros & Cons

• Pros: reusable, secure (permission-controlled), potential performance gains.
• Cons: higher complexity, tricky version control and testing, DBMS vendor lock-in.

7.4 Procedure vs. Function

• Functions must return a value and can appear inside SELECT queries.
• Procedures may omit a return value, use OUT parameters, and manage transactions.

8. Transactions

8.1 Definition

• A transaction is a logical unit of work that groups multiple SQL statements. Commit all if successful, otherwise roll back to maintain consistency.

8.2 ACID Properties

1. Atomicity: all-or-nothing execution.
2. Consistency: preserves integrity constraints.
3. Isolation: concurrent transactions do not interfere.
4. Durability: committed changes survive failures.

8.3 Isolation Levels

• Read Uncommitted: allows dirty reads.
• Read Committed: prevents dirty reads (default in many systems).
• Repeatable Read: guarantees repeatable reads; prevents non-repeatable reads.
• Serializable: equivalent to serial execution; safest but slowest.

8.4 Concurrency Control

• Locks (shared/exclusive, two-phase locking), optimistic control, timestamp ordering, MVCC.

8.5 Design Tips

• Keep transactions short to avoid deadlocks and lock contention.
• Common pattern: BEGIN; ...; COMMIT; with ROLLBACK; on errors.

9. Production Checklist

• Balance normalization and denormalization according to read/write patterns.
• Maintain only necessary indexes and review usage statistics regularly.
• Include logging and error handling in triggers/procedures for auditability.
