Operating Systems

1. History and Concepts

1.1 Batch Processing

• Early OSes executed a single job at a time with no user intervention.
• Operators manually queued jobs; the next job started only after the previous finished.
• Idle CPU time abounded while waiting for I/O, making computation inefficient.

1.2 Limitations of Batch

1. CPU idle time: Fast CPUs waited for slow I/O devices.
2. Slow job switching: Manual intervention delayed the transition between jobs.

1.3 Spooling (Fixes Issue 1)

• Buffers I/O so computation and device work overlap.
• Example: printer spooling—documents are queued on disk; printers fetch at their own pace while the CPU continues other work.
• Benefit: CPU need not stall for I/O completion.
• Caveat: If the program depends immediately on I/O results (e.g., read()), spooling alone cannot help.

1.4 Automatic Job Sequencing (Fixes Issue 2)

• Scheduling software automatically loads the next job as soon as the previous one finishes.
• Improves throughput compared with manual batching.
• Requires multiprogramming to keep multiple jobs resident in memory.

1.5 Multiprogramming & Time Sharing

• Multiple jobs reside in memory; CPU switches to another while the current one waits for I/O.
• FCFS plus priority-based policies balance fairness.
• Time sharing: CPU time is sliced so each job sees frequent progress. Heavy context switching gives the illusion of concurrency but adds overhead.

2. OS and Computer-System Structure

2.1 Four Components

1. Hardware: CPU, memory, I/O devices provide raw resources.
2. Operating System: Arbitrates resource access among programs.
3. Application Programs: Decide how resources are used to satisfy user tasks.
4. Users: People or other systems interacting with the computer.

2.2 Bus Architecture

• Early machines used a single bus—CPU, memory, I/O shared one channel—causing bottlenecks.
• Hierarchical dual-bus design emerged:
  • System bus: connects fast CPU/memory.
  • I/O bus: connects slower peripherals.
  • Northbridge: controller for high-speed devices.
  • Southbridge: handles slower devices and legacy ports.

3. Execution Modes: User vs. Kernel

• CPUs provide at least two privilege levels for system protection.
• Each mode controls which instructions and memory regions are accessible.

3.1 Kernel Mode

• Privileged; OS services, drivers, and resource managers run here with full hardware access.

3.2 User Mode

• Restricted; applications cannot execute privileged instructions and must request services via the OS.

3.3 Mode Switching

• System calls, interrupts, and traps flip the mode bit and jump into kernel handlers.
• After handling, control returns to user mode at the interrupted point.

4. CPU Event Handling

4.1 Hardware Interrupts

• Asynchronous events from devices.
• Sequence: save context → jump to ISR → perform service → restore context → resume execution.
• Priorities decide which interrupts pre-empt others; keep ISRs short.

4.2 Traps (Software Interrupts)

• Synchronous events within a program: e.g., divide-by-zero, system calls.
• Trigger a switch to kernel mode but may reuse existing context without full saving.

4.3 I/O Device Components

• Bus: data, address, and control lines.
• Device registers: control, status, input, output; mapped to memory for CPU access.
• Controller: intermediates between devices and buses, arbitrating use.

5. Device Access Methods

5.1 I/O Instructions

• CPU-specific instructions communicate directly with devices.
• Non-portable because instruction sets differ.

5.2 Memory-Mapped I/O

• Maps device registers into the main address space so ordinary loads/stores access hardware.
• Improves portability and programming simplicity.

6. I/O Completion Techniques

6.1 Polling

• CPU repeatedly checks device status.
• Fast response for quick devices but wastes CPU cycles when waiting.

6.2 Interrupt-Driven I/O

• CPU continues other tasks until a device interrupts to signal completion.
• Saves busy-wait time but incurs context-switch overhead and may delay detection of very fast events.

Rule of thumb: Fast devices favour polling; slower ones benefit from interrupts.

7. Data Transfer Methods

7.1 Programmed I/O

• CPU performs all data movement; expensive for large transfers.

7.2 Direct Memory Access (DMA)

• A DMA controller transfers data between memory and devices on behalf of the CPU.
• Process: CPU issues command → DMA moves data → completion interrupt notifies CPU.
• Pros: frees CPU cycles; excels for high-volume transfers.
• Cons: additional hardware cost and possible bus contention.

8. OS Design Considerations

8.1 General vs. Special Purpose

• General-purpose OSes serve diverse workloads; special-purpose OSes target embedded, real-time, or appliance scenarios.
• Balancing performance, fairness, and reliability requires deliberate trade-offs.

8.2 Layering vs. Modularity

• Layering: strict top-down structure; upper layers use lower-layer services only.
• Modularity: independent components communicate through explicit interfaces; freer ordering but demands dependency management.
• Modern OSes blend both: layered architecture populated with modular subsystems for stability and extensibility.

9. Kernel Structures and System Calls

9.1 System Calls & Mode Switch

• User code invokes an API → generates a trap → CPU enters kernel mode → trap handler executes → returns to user mode.

9.2 Parameter Passing

1. Registers: fastest but few parameters fit.
2. Memory blocks: store arguments in memory and pass the address.
3. Stack: push arguments in user mode; kernel pops them.

9.3 Monolithic Kernel

• All kernel services share one address space.
• Pros: minimal overhead for cross-service calls.
• Cons: tightly coupled; a faulty module can crash the entire kernel.

9.4 Address Spaces

• Define accessible address ranges. Sharing the same space allows direct referencing; separate spaces reinforce protection boundaries.

9.5 Microkernel

• Decomposes services into user-space servers communicating via IPC.
• Pros: low coupling, easy maintenance, unload unused services.
• Cons: frequent address-space switches and IPC overhead can hurt performance.

9.6 Hybrid Kernel

• Real-world kernels typically combine monolithic cores with loadable modules or user-space servers, balancing performance and flexibility.
